Rock Caravan

The Avida Rock is an off road caravan, it is light weight and has a modern interior design that allows you to explore the remote parts of Australia in style.

There are a couple of layouts available; Choose to travel as just a couple, or with your mates or why not take the whole family with the bunk bed option?

Discover more

Get the details

CV6436BB2 Rock Caravan

The Emerald CV5432QB caravan suits a young travelling family and has an incredible amount of living space and functionality. There is a choice of single beds or a queen bed at the front of the caravan, and in the living area you can choose between a dinette which also converts into a sleeping area suitable for two smaller travellers (perfect for the kids) or a lounge area. The bathroom is located conveniently at the rear of the caravan and is separated from the rest of the living area which the door is closed.

Specifications of the CV6436BB2 Rock Off Road Caravan.

Model Travel Length* External Height Ball mass (empty)
Approx*
Tare weight
Approx*
CV6436BB2 8600mm 3150mm 194kg 2585kg

* Note: The Tare and Ball weights in the table above are approximate only for the tourer model. Weights will vary depending on the options fitted at both factory and dealer. To find our more information consult your dealer.

Attribute Value
Exterior Body Length 6375mm
Exterior Width (inc. awning) 2495mm
Exterior Height 3150mm
Interior Height 2015mm
Axle Quantity Tandem

CV6534 Rock Caravan

Specifications of the CV6534 Rock Off Road Caravan.

Model Travel Length* External Height Ball mass (empty)
Approx*
Tare weight
Approx*
CV6534 8800mm 3150mm TBAkg TBAkg

* Note: The Tare and Ball weights in the table above are approximate only for the tourer model. Weights will vary depending on the options fitted at both factory and dealer. To find our more information consult your dealer.

Attribute Value
Exterior Body Length 6575mm
Exterior Width (inc. awning) 2495mm
Exterior Height 3150mm
Interior Height 2015mm
Axle Quantity Tandem

Specifications

Lengths

Model Exterior
Body Length
Exterior Width
(inc. awning)
Interior Height Axle Quantity
20 Foot – 64 Series Layout 6375mm 2495mm 2015mm Tandem
21 Foot – 65 Series Layout TBAmm 2495mm 2015mm Tandem

Due to continuous improvement, specifications are subject to change without notice.

Weights & Capacities

Model Travel Length External Travel Height Ball mass (empty)
Approx.*
Tare weight
Approx.*
CV6436BB2 8600mm 3150mm TBAkg 2585kg
CV6534 TBAmm 3150mm TBAkg TBAkg

* Note: The Tare and Ball weights in the table above are approximate only. Weights will vary depending on the options fitted at both factory and dealer. To find out more information consult your dealer.

Features

You can compare the Rock features with up to three other ranges by clicking below

Rock Wave Pop Top Emerald Topaz
Rock
green tick = Standard
red cross = Not available
O = Option
* = Select models
 Rock Caravan thumb
Off-Road
QUALITY INCLUSIONS Rock
Air conditioner – 240V roof mounted reverse cycle green tick
Avida’s unique, strong, highly insulated and light weight sandwich panel construction with aluminium underfloor protection green tick
Compliance – Certified weight certificate ex-factory with every vehicle green tick
Compliance – RVMAP industry accredited manufacturer (look for the accreditation key) green tick
Fridge – 190L 2 door automatic energy selection fridge / freezer O
Fridge – 150L automatic energy selection fridge/freezer red cross
Front wall – Aerodynamic moulded front red cross
Microwave – Carousel microwave green tick
Oven – Recessed 3 burner LPG stainless steel stove +1 electric cook top with gas griller combo & glass lid for extra bench space and gas oven O
Range hood – Stainless steel with fan & light green tick
Residential soft close drawers green tick
Solar – Solar panels with regulator green tick
Stove – Recessed 3 burner LPG stainless steel stove + 1 electric cook top with gas griller combo & glass lid for extra bench space green tick
TV – with DVD Player, wind up TV antenna with signal booster green tick
Ultra leather upholstery green tick
Washing machine green tick
Water – 2 x 120ltr water tanks plumbed independently green tick
Water tank – Dual filling with control to separate your water storage green tick
INTERIOR HIGHLIGHTS Rock
Bathroom door – Aluminium red cross
Bathroom door – Concertina red cross
Bathroom with shower, toilet & porcelain sink green tick
Battery – 100A red cross
Battery – Integrated battery charger & power supply green tick
Battery – Integrated display & controller unit for water tank & battery management green tick
Battery – Additional battery O
Battery – Wireless battery management through app O
Bed – Lift up bed on gas struts for easy lifting with storage under bed green tick
Bed – Queen size 1,520mm width green tick
Cupboards – Modern contemporary super gloss finish with aluminium extrusion in overhead cabinets for strength green tick
Cupboards – Timber grain with 3D finish (curved in Topaz) with aluminium extrusion in overhead cabinets for strength O
Drawers – Metal runners plus large pots & pans storage green tick
Fridge – Compressor fridge green tick
Handle free overhead cupboards green tick
Heating – Gas heater O
Hot water system – 240V & gas system with 12V electric start green tick
Lighting – 12V LED lighting green tick
Lighting – LED mood lighting throughout green tick
Mattress – Multilayered memory comfort green tick
Mirror – Large mirror with lights over vanity green tick
Pantry – Slide out pantry green tick
Power – 12V & 240V power systems with 240V external GPO green tick
Roof Hatch – 500mm x 700mm in living room green tick
Roof hatch in bathroom red cross
Roof hatch with 12V fan in bathroom green tick
Separate tap at sink with water filter green tick
Shower – Large separate shower with aluminium shower screen door red cross
Shower – Large separate shower with roller shower screen door green tick
Stereo – With AUX & USB ports red cross
Stereo – With bluetooth, AUX & USB ports & external speakers green tick
Storage – Ample storage throughout & under bed green tick
Swivel bracket fitted to lift up TV models red cross
Table – Adjustable & removable swivel dining table green tick
Table – Tri-fold table* O
Table – Wall mounted folding leg table (dinette models) red cross
TV – Additional television with DVD player red cross
TV – Satellite TV receiver O
Windows – Curtains O
Windows – Enormous dual pane flush mounted windows with fly screens and block out blinds green tick
EXTERIOR HIGHLIGHTS Rock
Awning – Electric O
Awning – Lights red cross
Awning – Lights and external working lights green tick
Awning – Quality roll out awning green tick
BBQ – External BBQ on slide O
Bike rack O
Boot – Front boot storage green tick
Entertainment Kit – with external speakers, USB & coax connection green tick
Entertainment unit – with radio speakers, table, 12V & 240V power and provisions for TV red cross
External slide out kitchen O
Gas – 2 x 4kg gas bottles in boot red cross
Gas – 2 x 9kg gas bottles in compartment red cross
Gas – 2 x 9kg gas bottles on A frame green tick
Handle – External grab handle red cross
Handle – External grab handle with integrated LED light green tick
Rear wall mouldings green tick
Shower – External shower with hot and cold water green tick
Spare wheel – Rear bumper mounted green tick
Spare wheel – Under floor mounted red cross
Step – Electric entry step O
Step – Manual pull out entry step green tick
Stone Protection – Premium stone guard protective coating on front or checker plating green tick
Storage – Pass through tunnel boot storage green tick
Table external – Surface mounted O
Tool box on draw bar with shelving and slide out trays green tick
Water – Grey water tank 125L
SAFETY FEATURES Rock
Brakes – AL-KO (1 x 12″) electric brakes – single axle red cross
Brakes – AL-KO (2 x 10″) electric brakes – tandem axle green tick
Breakaway system green tick
Earth leakage protector – 240V green tick
Entry door – Four point lock with security screen green tick
ESC – AL-KO electronic stability control (ESC) O
Fire extinguisher green tick
Lighting – High mount brake light red cross
LP gas leak detector green tick
Protector – External front window protector shade red cross
Reversing camera green tick
Smoke detector green tick
CHASSIS FEATURES Rock
Brakes – Dexter premium brakes green tick
Chassis – Revolutionary hot dipped galvanised chassis green tick
Corner stedy – AL-KO corner steady stabilisers with foot pads green tick
Extended draw bar green tick
Jockey wheel – AL-KO 150mm centre mounted green tick
Plug – 12 Pin car / loom plug green tick
Stone Guard – External front mesh stone guard on draw bar green tick
Suspension – Leaf springs red cross
Suspension – Powder coated Cruisemaster CRS independent with shock absorbers red cross
Water – External tap on A frame green tick
Wheels – Machined sports alloy wheels including spare 16″
Wheels – 225/70/15 tyres red cross
Wheels – 245/75R16 tyres green tick
MULTI TERRAIN PACK (UPGRADE) Rock
Suspension – Cruisemaster CRS independent coil red cross
Solar Panels with regulator red cross
Checker plate – Side wall stone protection red cross
Larger Tyres – 235/75R15 red cross
Wheels – Black alloys red cross
Coupling type – DO35 off road green tick
Grey water tank green tick
BBQ fitting – External green tick
Brake magnets – AL-KO off road red cross
Decals – Multi Terrain design red cross
External shower green tick
Front window protector red cross
Higher ground clearance red cross
J mould external corner extrusion colour – Black green tick
Wall/Floor extrusion colour – Black green tick
Water tank stone guard type – Heavy duty green tick
EXPLORER PACK (UPGRADE) Rock
Suspension – Cruisemaster XT independent coil green tick
Checker plate – increased height side wall stone protection green tick
Decals – Explorer design red cross
Brush protection rails at floor level green tick
16” Alloy sports wheels green tick
16” Tyres – 245/75R16 green tick
Stone guard on A frame green tick
Grey water tank (excludes single axle) red cross
Jerry can provision green tick
